Products Details
This laboratory roll-to-roll hot melt adhesive coater is designed for adhesive formulation evaluation, coating process development, and small-scale coating verification.
Equipped with a temperature-controlled doctor blade coating head and lamination unit, the machine supports continuous coating and release liner transfer coating processes for hot melt adhesives and pressure-sensitive adhesives (PSAs).
With a compact structure and flexible parameter adjustment, it is suitable for adhesive manufacturers, material researchers, and laboratories to optimize coating parameters, evaluate adhesive performance, and validate new products before scale-up production.
Products Specification
|
Power Supply |
Single-phase AC 220V±10% / Three-phase AC 380V±10%, 50Hz; customizable (excluding corona treatment) |
|
Optional |
AC 110V, 60Hz |
|
Air Supply |
0.5-0.8MPa compressed air |
|
Coating Type |
Continuous coating |
|
Guide Roll Width |
300mm |
|
Coating Width |
0-280mm, adjustable via baffles (customizable) |
|
Maximum line speed: |
0.01–4.5 m/min |
|
Adhesive Coating Thickness(wet film): |
0.02–5 mm (depending on adhesive properties and coating method) |
|
DoctorBlade Adjustment |
Manual adjustment |
|
Weight |
80kg (subject to actual weight) |
|
Overall Dimensions |
L 1200 mm x W 580 mm x H 724 mm(subject to actual dimensions) |
Machine Configuration
Unwinding Unit
Doctor Blade Coating Head
Lamination Unit
Rewinding Unit
Web Tension control
Product Details
Temperature-Controlled Doctor Blade Coating System
The doctor blade assembly and support plate are equipped with temperature sensors, allowing independent temperature adjustment through the control system.
The temperature control range is 0–200°C, helping maintain adhesive viscosity stability during the coating process and improving coating consistency.
Manual Coating Gap Adjustment
The coating gap is manually adjusted through the doctor blade mechanism with feeler gauges, allowing precise control of wet adhesive thickness according to process requirements.
Adjustable Coating Width
The coating width can be adjusted from 0 to 280 mm through side dams, providing flexibility for different adhesive coating trials.
Flexible Coating and Lamination Process
The machine supports:
Direct hot melt adhesive coating
Release liner transfer coating
Adhesive lamination onto flexible substrates
Suitable substrates include release paper, release film, plastic films, and other flexible web materials.
Configuration Options
The standard machine does not include:
Drying oven
Corona treatment unit
Additional modules can be customized according to specific coating requirements
Applications
Compatible Hot Melt Adhesive Types
The machine is suitable for various hot melt adhesive materials, including:
EVA (Ethylene Vinyl Acetate)
PUR (Polyurethane Reactive Hot Melt Adhesive)
Rubber-Based Pressure-Sensitive Adhesives (PSA)
SIS / SBS Thermoplastic Elastomer Adhesives
PO (Polyolefin) Hot Melt Adhesives
Coating Processes
Direct Adhesive Coating
Release Liner Transfer Coating
Hot Melt Adhesive Lamination
Target Industries
Adhesive Tape Manufacturing
Label Materials
Protective Films
Medical Adhesive Products
Electronics Adhesive Materials
Flexible Material Lamination
application Examples(Video)
Products Detail Images
