Multi Functional Coating Machine

Product Introduction:
Item: Multi-functional coating machine
Accuracy: ≤3μm
Width of coating: 400mm
Coating speed: 10m/min
Lead Time: According to quantity and seasons
OEM is accepted, your tag, label, logo

Send Inquiry

Product Introduction

This Multi functional coating machine is equipped with a doctor blade slit and various micro-concave coating heads, suitable for roll substrates, providing uniform coating. The coating thickness and dimensional parameters are adjustable, and the oven length can be selected according to the coating characteristics. The equipment is widely used in industries such as new materials, new energy, medical, packaging, and electronic materials.

Product Features

1. The Multi functional coating machine offers three coating methods: blade, slot, and concave, meeting diverse slurry application needs with high coating precision;

2. Modular design allows for selection of drying methods or the addition of functional modules such as corona treatment, cutting, and packaging;

3. PLC control and HMI human-machine interface operation; compact size and easy to use;

4. Wide coating window adaptable to various coating scenarios, especially suitable for early-stage material research and development testing and small-batch production.

Parameters

Coting type	Comma scraper, slot coating, micro-recessed coating
Guide roller width	500mm
substrate width	450mm
Coating width	400mm
Speed of machine	10m/min
Accuracy	Continuous single-sided coating thickness: Coating thickness is CNC adjustable; thickness accuracy: ≤3μm; coating thickness: ≤±3μm
Dimension	L: 4200mmW: 960mmH: 1700mm (Based on actual dimensions)
Coating speed	according to curing time
